All lanes : Anti-ESAM antibody (ab74777) at 1 µg/mlLane 1 : Heart (Human) Tissue Lysate - adult normal tissue (ab29431)Lane 2 : Liver (Human) Tissue Lysate - adult normal tissue (ab29889)Lane 3 : Kidney (Human) Tissue Lysate - adult normal tissue (ab30203)Lane 4 : HepG2 (Human hepatocellular liver carcinoma cell line) Whole Cell LysateLane 5 : HEK293 (Human embryonic kidney cell line) Whole Cell LysateLane 6 : Lung (Human) Tissue LysateLysates/proteins at 10 µg per lane.SecondaryAnnexin A2 293T Transfected Lysate - (positive control) (ab94080) at 1/5000 dilutiondeveloped using the ECL techniquePerformed under reducing conditions.
ICC/IF image of ab74777 stained MCF7 cells. The cells were 4% PFA fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab74777, 5µg/ml) overnight at +4°C. The secondary antibody (green) was Alexa Fluor® 488 goat anti-rabbit IgG (H+L) used at a 1/1000 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM. This antibody also gave a positive result in 4% PFA fixed (10 min) HepG2 cells at 5µg/ml, and in 100% methanol fixed (5 min) HepG2 and MCF7 cells at 5µg/ml.
