Anti-SV2C antibody (ab33892) at 1 µg/ml + Liver (Rat) Tissue Lysate at 10 µgSecondaryIRDye 680 Conjugated Goat Anti-Rabbit IgG (H+L) at 1/10000 dilutionPerformed under reducing conditions.
ICC/IF image of ab33892 stained PC12 cells. The cells were 4% PFA fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody (ab33892, 1µg/ml) overnight at +4°C. The secondary antibody (green) was Alexa Fluor® 488 goat anti-rabbit IgG (H+L) used at a 1/1000 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue).
ab33892 staining SV2C in mouse brain tissue section by Immunohistochemistry (PFA perfusion fixed frozen sections). Tissue from 4% PFA perfused animals underwent overnight fixation in 4% paraformaldehyde, cryoprotected in 30% sucrose and cut using cryostat.The primary antibody was diluted, 1/1000 (PBS + 0.3% Triton X100) and incubated with sample for 18 hours at 20°C. An abcam antibody ab60314, Chromeo488 conjugated goat polyclonal to rabbit IgG was used undiluted as secondary. The picture was taken at level of hippocampus.See Abreview
