Synaptojanin 1

Name	Synaptojanin 1
Supplier	Synaptic Systems
Catalog	145 103
Host	Rabbit
Clonality	Polyclonal
Applications	WB IHC
Species Reactivities	Rat, Mouse, Hamster
Antigen	Synthetic peptide CGVGAPPSPGVTRREME (aa 1140 - 1155 in isoform 2) coupled to key-hole limpet hemocyanin via an added N-terminal cysteine residue.
Purity/Format	affinity purified 2
Description	Rabbit Polyclonal
Gene	Synj1
Supplier Page	Shop

Product images

$Cat. No. 145 003 / 145 103 antibody dilution: 1 : 200 sample: crude synaptosomal fraction of rat brain (P2)$ Cat. No. 145 003 / 145 103 antibody dilution: 1 : 200 sample: crude synaptosomal fraction of rat brain (P2)

Cat. No. 145 103 Indirect immunostaining of a PFA fixed mouse retina section (dilution 1 : 5000). Synaptojanin-positive structures have been revealed with fluorochromated secondary antibodies. ONL: Outer nuclear layer OPL: Outer plexiform layer INL: Inner nuclear layer IPL: Inner plexiform layer GCL: Ganglion cell layer Courtesy: H. Regus-Leidig and H. Brandstätter, Institute of Animal Physiology, Department of Biology, University of Erlangen-Nürnberg.
