Anti-CRMP2 (phospho T514) antibody
| Name | Anti-CRMP2 (phospho T514) antibody |
|---|---|
| Supplier | Abcam |
| Catalog | ab85934 |
| Prices | $385.00 |
| Sizes | 100 µg |
| Host | Rabbit |
| Clonality | Polyclonal |
| Isotype | IgG |
| Applications | ICC/IF ICC/IF WB IP |
| Species Reactivities | Mouse, Rat, Human, Chicken, Bovine, Orangutan |
| Antigen | Synthetic peptide conjugated to KLH derived from within residues 500 to the C-terminus of Human CRMP2, phosphorylated at T514 |
| Description | Rabbit Polyclonal |
| Gene | DPYSL2 |
| Conjugate | Unconjugated |
| Supplier Page | Shop |
Product images
All lanes : Anti-CRMP2 (phospho T514) antibody (ab85934) at 1 µg/mlLane 1 : Brain (Human) Tissue Lysate - adult normal tissue (ab29466)Lane 2 : Brain (Mouse) Tissue Lysate Lane 3 : Brain (Rat) Tissue Lysate Lane 4 : Brain (Human) Tissue Lysate - adult normal tissue (ab29466) with Human Dihydropyrimidinase-related protein 2 Synth (508 - 520) (Phosphorylated T 514)Lane 5 : Brain (Mouse) Tissue Lysate with Human Dihydropyrimidinase-related protein 2 Synth (508 - 520) (Phosphorylated T 514)Lane 6 : Brain (Rat) Tissue Lysate with Human Dihydropyrimidinase-related protein 2 Synth (508 - 520) (Phosphorylated T 514)Lane 7 : Brain (Human) Tissue Lysate - adult normal tissue (ab29466) with Human Dihydropyrimidinase-related protein 2 Synth (508 - 520) (Non-Modified)Lane 8 : Brain (Mouse) Tissue Lysate with Human Dihydropyrimidinase-related protein 2 Synth (508 - 520) (Non-Modified)Lane 9 : Brain (Rat) Tissue Lysate with Human Dihydropyrimidinase-related protein 2 Synth (508 - 520) (Non-Modified)L
ICC/IF image of ab85934 stained PC12 cells. The cells were 4% formaldehyde fixed (10 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody ab85934 at 5µg/ml overnight at +4°C. The secondary antibody (green) was Alexa Fluor® 488 goat anti- rabbit IgG (H+L) used at a 1/1000 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM.
![CRMP2 was immunoprecipitated using 0.5mg Mouse Brain tissue, 5µg of Rabbit polyclonal to CRMP2 and 50µl of protein G magnetic beads (+). No antibody was added to the control (-). The antibody was incubated under agitation with Protein G beads for 10min, Mouse Brain tissue lysate lysate diluted in RIPA buffer was added to each sample and incubated for a further 10min under agitation.Proteins were eluted by addition of 40µl SDS loading buffer and incubated for 10min at 70oC; 10µl of each sample was separated on a SDS PAGE gel, transferred to a nitrocellulose membrane, blocked with 5% BSA and probed with ab85934.Secondary: Mouse monoclonal [SB62a] Secondary Antibody to Rabbit IgG light chain (HRP) (ab99697).Band: 70kDa; CRMP2](http://www.bioprodhub.com/system/product_images/ab_products/2/sub_2/2431_CRMP2-Primary-antibodies-ab85934-3.jpg)
CRMP2 was immunoprecipitated using 0.5mg Mouse Brain tissue, 5µg of Rabbit polyclonal to CRMP2 and 50µl of protein G magnetic beads (+). No antibody was added to the control (-). The antibody was incubated under agitation with Protein G beads for 10min, Mouse Brain tissue lysate lysate diluted in RIPA buffer was added to each sample and incubated for a further 10min under agitation.Proteins were eluted by addition of 40µl SDS loading buffer and incubated for 10min at 70oC; 10µl of each sample was separated on a SDS PAGE gel, transferred to a nitrocellulose membrane, blocked with 5% BSA and probed with ab85934.Secondary: Mouse monoclonal [SB62a] Secondary Antibody to Rabbit IgG light chain (HRP) (ab99697).Band: 70kDa; CRMP2
