All lanes : Anti-Angiogenin antibody (ab95389) at 1 µg/mlLane 1 : Lung (Human) Tissue Lysate Lane 2 : Liver (Human) Tissue Lysate - adult normal tissue (ab29889)Lysates/proteins at 10 µg per lane.SecondaryGoat polyclonal Secondary Antibody to Rabbit IgG - H&L (HRP), pre-adsorbed at 1/5000 dilutiondeveloped using the ECL techniquePerformed under reducing conditions.
ICC/IF image of ab95389 stained MCF-7 cells. The cells were 100% methanol fixed (5 min) and then incubated in 1%BSA / 10% normal goat serum / 0.3M glycine in 0.1% PBS-Tween for 1h to permeabilise the cells and block non-specific protein-protein interactions. The cells were then incubated with the antibody ab95389 at 5µg/ml overnight at +4°C. The secondary antibody (green) was DyLight® 488 goat anti- rabbit (ab96899) IgG (H+L) used at a 1/1000 dilution for 1h. Alexa Fluor® 594 WGA was used to label plasma membranes (red) at a 1/200 dilution for 1h. DAPI was used to stain the cell nuclei (blue) at a concentration of 1.43µM.
